Mikrotik to Mikrotik-Cisco Bonding – Reference Notes

This post was made for self reference purposes, so that I can find the configs easily from this page when needed again.

This post describes possible methods of creating ethernet interfaces bonding between Mikrotik to Cisco (etherchannel) or Mikrotik to Mikrotik to achieve load balancing & failover to achieve higher speed from multiple ethernet interfaces. Bonding is a technology that allows aggregation of multiple Ethernet-like interfaces into a single virtual link, thus getting Maximum Throughput and providing failover. You can use this technique to create bonding between WAN Cisco switch/R to User Mikrotik, then from User mikrotik to User distribution vlan switch. lots of combinations you can create in this regard.

Possible Scenarios:

OP have Mikrotik CCR1036 routerboard with SFP+. ISP have given OP with 10G of SFP+ connectivity on OP WAN Mikrotik router. but on user side router OP have simple CCR1036 with 1G ports only. So the wan link from 1036-wan to 1036-LAN is choking at  1G. Proper solution is to have back to back 10G connectivity between all routers, but since it requires cash investment, therefore the OP sometimes chooses workaround to fulfill the requirements for the time being. BONDING is one of that workaround that can be chosen. although I try to avoid using it as much as possible & always look for 10/25G solutions.

Hardware Used in this post

• Mikrotik: RB2011
• Cisco 36450 24 Ports Switch
• In general you can use upto 8 ports Bonding, should be of same type/speed.
• All ports should be enabled before adding them to bond.

Option-1# Mikrotik to Cisco Bonding (using 1Gx2 interfaces to achieve failover / load balancing / higher speed)

Using any two interfaces, we are creating 2 port Bonding interface. Example from Mikrotik Port 9 & 10 we will connect two cables connected to Cisco Switch port 23 & 24.

#Mikrotik Example Code , using port 9 & 10

# Cisco Switch Example Code, suing port 23 & 24

Note: If you are doing Cisco to Cisco Port Bonding , then you need to repeat above code on 2nd switch too

Option-2# Mikrotik to Mikrotik Bonding

Its very simple. Just issue below command on both mikrotik and connect the cables from designated interfaces, assign IP, and you are good to go …

Some Helpful CMD’s related to etherchannel on Cisco switch …

Note: Before you connect both cable, make sure to add the config on Mikrotik & Cisco side, Else cisco port will get shut dueto STP protection to avoid loop.

Configuring EtherChannel Load Balancing

To view etherchannel load balancing setting, use the show command …

To configure load balancing, use the following commands:
